FA41861-03

0.250 Conductor Diameter, SAPPHIRE INSULATOR, 1 Pin 12kV 56 Amp Nickel Conductor Weld

0.250 Conductor Diameter, SAPPHIRE INSULATOR, 1 Pin 12kV 56 Amp Nickel Conductor Weld
  • Number of Conductors:1
  • Style:Power
  • Voltage: 12000 Volts
  • Current: 56.0 Amps
  • Mount:Weld
0.250 Conductor Diameter, SAPPHIRE INSULATOR, 1 Pin 12kV 56 Amp Nickel Conductor Weld
PART NUMBER:
FA41861-03
PRICE:
CALL FOR PRICE
Drawing Not Available
Login to Download 3D
Product Specifications:
Number of Conductors 1
Style Power
Voltage 12,000 Volts
Current 56.0 Amps
Mount Style Weld
Conductor Diameter 0.250 Inches
Conductor Material Nickel
Temperature Range Call for Temperature Rating
Pressure Maximum Call for psig
Plug Other

All SST parts are customizable! We regularly make modifications to our catalog parts and offer totally custom feedthroughs and hermetic connectors. If your project requires changes from what you see listed in these product specifications, please reach out to us using the contact form on this page.
