KT10657

6 Pin 5015 Style Circular Connector, 700V, 4.8 Amp, Alumel Conductors in Weld adapter With Plug

6 Pin 5015 Style Circular Connector, 700V, 4.8 Amp, Alumel Conductors in Weld adapter With Plug
6 Pin 5015 Style Circular Connector, 700V, 4.8 Amp, Alumel Conductors in Weld adapter With Plug
PART NUMBER:
KT10657
PRICE:
$235.50 USD
Contact Us for 3D Model
Product Specifications:
Number of Conductors 6
Style Circular - 5015 Series
Voltage 700 Volts
Current 4.8 Amps
Mount Style Weld
Conductor Diameter 0.062 Inches
Conductor Material Alumel
Temperature Range -65 to 165 °C
Pressure Maximum 550 psig
Plug Included

All SST parts are customizable! We regularly make modifications to our catalog parts and offer totally custom feedthroughs and hermetic connectors. If your project requires changes from what you see listed in these product specifications, please reach out to us using the contact form on this page.
