FA13019-02

Thermocouple, Type J, 1 Pair with two 3kV, 27 Amp, Copper Conductors in a CF2.75 With Spade Plug

Thermocouple, Type J, 1 Pair with two 3kV, 27 Amp, Copper Conductors in a CF2.75 With Spade Plug
  • Number of Pairs:1
  • Thermocouple:J
  • Style:Spade Type
  • With Power?:With Power
  • Voltage: 3000 Volts
Thermocouple, Type J, 1 Pair with two 3kV, 27 Amp, Copper Conductors in a CF2.75 With Spade Plug
PART NUMBER:
FA13019-02
PRICE:
$235.00 USD
Login to Download 3D
Product Specifications:
Number of Pairs 1
Thermocouple Type J
Style Spade Type
With Power? With Power
Voltage 3,000 Volts
Current 27.0 Amps
Mount Style CF2.75
Temperature Range -269 to 450 °C
Pressure Maximum 800 psig
Plug Included

All SST parts are customizable! We regularly make modifications to our catalog parts and offer totally custom feedthroughs and hermetic connectors. If your project requires changes from what you see listed in these product specifications, please reach out to us using the contact form on this page.

Get in touch to place an order

Complete the inquiry form to request more information and discuss your application with one of our representatives. As always, be sure to ask about volume discounts. SST reserves the right to modify pricing at any time.
